Camera’s
Before adding any cameras to the Waze map, you must be sure you are accurately reporting a camera installation. Many devices may have similar appearances, but very different functions.
- The current camera image in the app as well as in WME implies that the camera captures the traffic from behind. Don’t be fooled. It may also catch you up front
- It is not possible to define a camera in such a way that it differentiates between traffic going straight or taking a turn at a junction.
- The Waze app warns about a camera if it is valid, points in the same direction as the road segment, and the driver is exceeding the limit set on the camera
Types of Camera’s
Speed camera
Used for permanently mounted cameras that monitor violations of maximum speeds.
- Speed Cameras should be placed at the location of the camera itself.
Red Light camera
Permanently mounted cameras monitor for red light violations and optionally for violations of maximum speeds. They show with a icon with a red and green light. Red Light cameras should be placed at the stop bar they are monitoring.
Combined cameras
In Belgium, all red light camera’s also measure speed. They are mapped with as a combination of Red Light camera and Speed camera
False camera
Sometimes a fake device is placed. These dummy cameras can be added to prevent people from reporting these dummies as actual cameras.
In the app a dummy camera looks like
Average speed cameras
Average speed cameras (ASC) measure speed over a certain distance. They are not mapped like the above cameras. Use the Average speed camera checkboxes on the road segments where the average speed is checked.
Mapping guidelines
- You can add a new camera from the menu at the left bar of the Map Editor
- Select the camera and choose the type in the left menu
- Location: Cameras should be placed over the roadway they are monitoring. The exact location depends on the type of camera (see above).
- Shutter Direction: When the camera icon is selected in the Map Editor, It does not matter if the real-life camera will take a picture from the back of a car after passing, or from the front before passing the camera.
- Place the correct quantity of cameras. You need one Camera per monitored direction. So if you have a 4-way intersection with 1 real life camera watching every direction, you need 4 cameras in Waze.
- Speed: The excess speed is set to the Speed Limit off the road it is monitoring.
